Featuers

Spot Lights

Spotlights are used for low cost, washdown intense illumination of a limited area. These new illuminators are available in a variety of beam angles and optimal working distances..

titleimg only if someone have been filling the title image

1Vision offers a wide selection of spotlights to suit any lighting need, in a variety of voltages, colors, and sizes.

Let us help you find the spotlight best suited for your application!

Find the spotlight that is best for you

Using our advanced search engine you can define the following characteristics to locate the spotlight most suited to your needs

Spot Lights Products
Part # Description CATEGORY SUB CATEGORY MANUFACTURER Size Datasheet Voltage Weight[g] Power Illumination Color DRAWING
LV14UV365

Ultraviolet (UV) Series Features:

  1. A peak emission wavelength of 365 nm.
  2. Provide image recognition at high contrast.
  3. Capture the surface of the subject more clearly than visible light.



Major applications:

  1. Photography use the difference in the scattering rate.
  2. Use with a CCD camera supporting the ultraviolet ray range.
  3. Detection of dirt on glass substrates and dust on CCD devices.
  4. Scan the image of the OR Code.
 Illumination Spot Lights; 3AM OD14-ID8 Download 24V 0.5W UV (365nm)
FR-SL205-W-24-N Metaphase’s new LED spotlight provides low cost, washdown illumination. These new illuminators are available in a variety of beam angles and optimal working distances. These lights are housed in rugged waterproof housing that can stand up to high pressure washdown environments.The standard spotlight has a coverage area of 8ft at a distance of 8ft. Other angles include: ± 12°, ± 16°, and ± 25° No expensive external current driver is required. The lights include an adjustable locking mounting bracket. Illumination Spot Lights; Metaphase 1.7ʺ Download 24V White
FR-SL205-W-24-M Metaphase’s new LED spotlight provides low cost, washdown illumination. These new illuminators are available in a variety of beam angles and optimal working distances. These lights are housed in rugged waterproof housing that can stand up to high pressure washdown environments.The standard spotlight has a coverage area of 8ft at a distance of 8ft. Other angles include: ± 12°, ± 16°, and ± 25° No expensive external current driver is required. The lights include an adjustable locking mounting bracket. Illumination Spot Lights; Metaphase 1.7ʺ Download 24V White
FR-SL205-W-24-W Metaphase’s new LED spotlight provides low cost, washdown illumination. These new illuminators are available in a variety of beam angles and optimal working distances. These lights are housed in rugged waterproof housing that can stand up to high pressure washdown environments.The standard spotlight has a coverage area of 8ft at a distance of 8ft. Other angles include: ± 12°, ± 16°, and ± 25° No expensive external current driver is required. The lights include an adjustable locking mounting bracket. Illumination Spot Lights; Metaphase 1.7ʺ Download 24V White
GL-LV14R

Spot Light Series Features:

  1. High-luminosity coaxial spot lights compatible with MARCO lenses
  2. Collecting optics by used light guides to maximum spot luminance
  3. Stable illumination in dedicated constant-voltage power source
  4. Small with easy and convenient handling
  5. Spot lighting
  6. HLV3 series allows 5 times brighter than HLV series,which has become the brightest spot light in Machine vision field.

Major applications:

  1. Coaxial lighting for highly reflective surfaces , such as wafers, metal surfaces, liquid-crystal and glass material.
  2. Mounted on movable modules.
 Illumination Spot Lights; 3AM OD14-ID8 Download 12V 16g 0.3W Red
GL-LV14W

Spot Light Series Features:

  1. High-luminosity coaxial spot lights compatible with MACRO lenses
  2. Collecting optics by used light guides to maximum spot luminance
  3. Stable illumination in dedicated constant-voltage power source
  4. Small with easy and convenient handling
  5. Spot lighting
  6. HLV3 series allows 5 times brighter than HLV series,which has become the brightest spot light in Machine vision field.

Major applications:

  1. Coaxial lighting for highly reflective surfaces , such as wafers, metal surfaces, liquid-crystal and glass material.
  2. Mounted on movable modules.
 Illumination Spot Lights; 3AM OD14-ID8 Download 12V 16g 0.3W White
GL-LV14B

Spot Light Series Features:

  1. High-luminosity coaxial spot lights compatible with MARCO lenses
  2. Collecting optics by used light guides to maximum spot luminance
  3. Stable illumination in dedicated constant-voltage power source
  4. Small with easy and convenient handling
  5. Spot lighting
  6. HLV3 series allows 5 times brighter than HLV series,which has become the brightest spot light in Machine vision field.

Major applications:

  1. Coaxial lighting for highly reflective surfaces , such as wafers, metal surfaces, liquid-crystal and glass material.
  2. Mounted on movable modules.
 Illumination Spot Lights; 3AM OD14-ID8 Download 12V 16g 0.3W Blue
GL-LV14G

Spot Light Series Features:

  1. High-luminosity coaxial spot lights compatible with MARCO lenses
  2. Collecting optics by used light guides to maximum spot luminance
  3. Stable illumination in dedicated constant-voltage power source
  4. Small with easy and convenient handling
  5. Spot lighting
  6. HLV3 series allows 5 times brighter than HLV series,which has become the brightest spot light in Machine vision field.

Major applications:

  1. Coaxial lighting for highly reflective surfaces , such as wafers, metal surfaces, liquid-crystal and glass material.
  2. Mounted on movable modules.
 Illumination Spot Lights; 3AM OD14-ID8 Download 12V 16g 0.3W Green
GL-LV14IR

Spot Light Series Features:

  1. High-luminosity coaxial spot lights compatible with MARCO lenses
  2. Collecting optics by used light guides to maximum spot luminance
  3. Stable illumination in dedicated constant-voltage power source
  4. Small with easy and convenient handling
  5. Spot lighting
  6. HLV3 series allows 5 times brighter than HLV series,which has become the brightest spot light in Machine vision field.

Major applications:

  1. Coaxial lighting for highly reflective surfaces , such as wafers, metal surfaces, liquid-crystal and glass material.
  2. Mounted on movable modules.
 Illumination Spot Lights; 3AM OD14-ID8 Download 12V 16g 0.3W Infra-Red (850nm)
GL-HLV28R

Spot Light Series Features:

  1. High-luminosity coaxial spot lights compatible with MARCO lenses
  2. Collecting optics by used light guides to maximum spot luminance
  3. Stable illumination in dedicated constant-voltage power source
  4. Small with easy and convenient handling
  5. Spot lighting
  6. HLV3 series allows 5 times brighter than HLV series,which has become the brightest spot light in Machine vision field.

Major applications:

  1. Coaxial lighting for highly reflective surfaces , such as wafers, metal surfaces, liquid-crystal and glass material.
  2. Mounted on movable modules.
 Illumination Spot Lights; 3AM OD14-ID8 Download 3.5V 39g 1.0W Red
GL-HLV28W

Spot Light Series Features:

  1. High-luminosity coaxial spot lights compatible with MARCO lenses
  2. Collecting optics by used light guides to maximum spot luminance
  3. Stable illumination in dedicated constant-voltage power source
  4. Small with easy and convenient handling
  5. Spot lighting
  6. HLV3 series allows 5 times brighter than HLV series,which has become the brightest spot light in Machine vision field.

Major applications:

  1. Coaxial lighting for highly reflective surfaces , such as wafers, metal surfaces, liquid-crystal and glass material.
  2. Mounted on movable modules.
 Illumination Spot Lights; 3AM OD14-ID8 Download 3.5V 39g 1.0W White
GL-HLV28B

Spot Light Series Features:

  1. High-luminosity coaxial spot lights compatible with MARCO lenses
  2. Collecting optics by used light guides to maximum spot luminance
  3. Stable illumination in dedicated constant-voltage power source
  4. Small with easy and convenient handling
  5. Spot lighting
  6. HLV3 series allows 5 times brighter than HLV series,which has become the brightest spot light in Machine vision field.

Major applications:

  1. Coaxial lighting for highly reflective surfaces , such as wafers, metal surfaces, liquid-crystal and glass material.
  2. Mounted on movable modules.
 Illumination Spot Lights; 3AM OD14-ID8 Download 3.5V 39g 1.0W Blue
GL-HLV28G

Spot Light Series Features:

  1. High-luminosity coaxial spot lights compatible with MARCO lenses
  2. Collecting optics by used light guides to maximum spot luminance
  3. Stable illumination in dedicated constant-voltage power source
  4. Small with easy and convenient handling
  5. Spot lighting
  6. HLV3 series allows 5 times brighter than HLV series,which has become the brightest spot light in Machine vision field.

Major applications:

  1. Coaxial lighting for highly reflective surfaces , such as wafers, metal surfaces, liquid-crystal and glass material.
  2. Mounted on movable modules.
 Illumination Spot Lights; 3AM OD14-ID8 Download 3.5V 39g 1.0W Green
GL-HLV2-28R

Spot Light Series Features:

  1. High-luminosity coaxial spot lights compatible with MARCO lenses
  2. Collecting optics by used light guides to maximum spot luminance
  3. Stable illumination in dedicated constant-voltage power source
  4. Small with easy and convenient handling
  5. Spot lighting
  6. HLV3 series allows 5 times brighter than HLV series,which has become the brightest spot light in Machine vision field.

Major applications:

  1. Coaxial lighting for highly reflective surfaces , such as wafers, metal surfaces, liquid-crystal and glass material.
  2. Mounted on movable modules.
 Illumination Spot Lights; 3AM OD14-ID8 Download 3.5V 55g 1.0W Red
GL-HLV2-28W

Spot Light Series Features:

  1. High-luminosity coaxial spot lights compatible with MARCO lenses
  2. Collecting optics by used light guides to maximum spot luminance
  3. Stable illumination in dedicated constant-voltage power source
  4. Small with easy and convenient handling
  5. Spot lighting
  6. HLV3 series allows 5 times brighter than HLV series,which has become the brightest spot light in Machine vision field.

Major applications:

  1. Coaxial lighting for highly reflective surfaces , such as wafers, metal surfaces, liquid-crystal and glass material.
  2. Mounted on movable modules.
 Illumination Spot Lights; 3AM OD14-ID8 Download 3.5V 55g 1.0W White
GL-HLV2-28B

Spot Light Series Features:

  1. High-luminosity coaxial spot lights compatible with MARCO lenses
  2. Collecting optics by used light guides to maximum spot luminance
  3. Stable illumination in dedicated constant-voltage power source
  4. Small with easy and convenient handling
  5. Spot lighting
  6. HLV3 series allows 5 times brighter than HLV series,which has become the brightest spot light in Machine vision field.

Major applications:

  1. Coaxial lighting for highly reflective surfaces , such as wafers, metal surfaces, liquid-crystal and glass material.
  2. Mounted on movable modules.
 Illumination Spot Lights; 3AM OD14-ID8 Download 3.5V 55g 1.0W Blue
GL-HLV2-28G

Spot Light Series Features:

  1. High-luminosity coaxial spot lights compatible with MARCO lenses
  2. Collecting optics by used light guides to maximum spot luminance
  3. Stable illumination in dedicated constant-voltage power source
  4. Small with easy and convenient handling
  5. Spot lighting
  6. HLV3 series allows 5 times brighter than HLV series,which has become the brightest spot light in Machine vision field.

Major applications:

  1. Coaxial lighting for highly reflective surfaces , such as wafers, metal surfaces, liquid-crystal and glass material.
  2. Mounted on movable modules.
 Illumination Spot Lights; 3AM OD14-ID8 Download 3.5V 55g 1.0W Green
GL-HLV2-32R

Spot Light Series Features:

  1. High-luminosity coaxial spot lights compatible with MARCO lenses
  2. Collecting optics by used light guides to maximum spot luminance
  3. Stable illumination in dedicated constant-voltage power source
  4. Small with easy and convenient handling
  5. Spot lighting
  6. HLV3 series allows 5 times brighter than HLV series,which has become the brightest spot light in Machine vision field.

Major applications:

  1. Coaxial lighting for highly reflective surfaces , such as wafers, metal surfaces, liquid-crystal and glass material.
  2. Mounted on movable modules.
 Illumination Spot Lights; 3AM OD14-ID8 Download 3.7V 90g 2.0W Red
GL-HLV2-32W

Spot Light Series Features:

  1. High-luminosity coaxial spot lights compatible with MARCO lenses
  2. Collecting optics by used light guides to maximum spot luminance
  3. Stable illumination in dedicated constant-voltage power source
  4. Small with easy and convenient handling
  5. Spot lighting
  6. HLV3 series allows 5 times brighter than HLV series,which has become the brightest spot light in Machine vision field.

Major applications:

  1. Coaxial lighting for highly reflective surfaces , such as wafers, metal surfaces, liquid-crystal and glass material.
  2. Mounted on movable modules.
 Illumination Spot Lights; 3AM OD14-ID8 Download 3.7V 90g 2.0W White
GL-HLV2-32B

Spot Light Series Features:

  1. High-luminosity coaxial spot lights compatible with MARCO lenses
  2. Collecting optics by used light guides to maximum spot luminance
  3. Stable illumination in dedicated constant-voltage power source
  4. Small with easy and convenient handling
  5. Spot lighting
  6. HLV3 series allows 5 times brighter than HLV series,which has become the brightest spot light in Machine vision field.

Major applications:

  1. Coaxial lighting for highly reflective surfaces , such as wafers, metal surfaces, liquid-crystal and glass material.
  2. Mounted on movable modules.
 Illumination Spot Lights; 3AM OD14-ID8 Download 3.7V 90g 2.0W Blue
GL-HLV2-32G

Spot Light Series Features:

  1. High-luminosity coaxial spot lights compatible with MARCO lenses
  2. Collecting optics by used light guides to maximum spot luminance
  3. Stable illumination in dedicated constant-voltage power source
  4. Small with easy and convenient handling
  5. Spot lighting
  6. HLV3 series allows 5 times brighter than HLV series,which has become the brightest spot light in Machine vision field.

Major applications:

  1. Coaxial lighting for highly reflective surfaces , such as wafers, metal surfaces, liquid-crystal and glass material.
  2. Mounted on movable modules.
 Illumination Spot Lights; 3AM OD14-ID8 Download 3.7V 90g 2.0W Green
GL-HLV3-24R

Spot Light Series Features:

  1. High-luminosity coaxial spot lights compatible with MARCO lenses
  2. Collecting optics by used light guides to maximum spot luminance
  3. Stable illumination in dedicated constant-voltage power source
  4. Small with easy and convenient handling
  5. Spot lighting
  6. HLV3 series allows 5 times brighter than HLV series,which has become the brightest spot light in Machine vision field.

Major applications:

  1. Coaxial lighting for highly reflective surfaces , such as wafers, metal surfaces, liquid-crystal and glass material.
  2. Mounted on movable modules.
 Illumination Spot Lights; 3AM OD14-ID8 Download 3.7V 40g 2.0W Red
GL-HLV3-24W

Spot Light Series Features:

  1. High-luminosity coaxial spot lights compatible with MARCO lenses
  2. Collecting optics by used light guides to maximum spot luminance
  3. Stable illumination in dedicated constant-voltage power source
  4. Small with easy and convenient handling
  5. Spot lighting
  6. HLV3 series allows 5 times brighter than HLV series,which has become the brightest spot light in Machine vision field.

Major applications:

  1. Coaxial lighting for highly reflective surfaces , such as wafers, metal surfaces, liquid-crystal and glass material.
  2. Mounted on movable modules.
 Illumination Spot Lights; 3AM OD14-ID8 Download 3.7V 40g 2.0W White
GL-HLV3-24B

Spot Light Series Features:

  1. High-luminosity coaxial spot lights compatible with MARCO lenses
  2. Collecting optics by used light guides to maximum spot luminance
  3. Stable illumination in dedicated constant-voltage power source
  4. Small with easy and convenient handling
  5. Spot lighting
  6. HLV3 series allows 5 times brighter than HLV series,which has become the brightest spot light in Machine vision field.

Major applications:

  1. Coaxial lighting for highly reflective surfaces , such as wafers, metal surfaces, liquid-crystal and glass material.
  2. Mounted on movable modules.
 Illumination Spot Lights; 3AM OD14-ID8 Download 3.7V 40g 2.0W Blue
GL-HLV3-24G

Spot Light Series Features:

  1. High-luminosity coaxial spot lights compatible with MARCO lenses
  2. Collecting optics by used light guides to maximum spot luminance
  3. Stable illumination in dedicated constant-voltage power source
  4. Small with easy and convenient handling
  5. Spot lighting
  6. HLV3 series allows 5 times brighter than HLV series,which has become the brightest spot light in Machine vision field.

Major applications:

  1. Coaxial lighting for highly reflective surfaces , such as wafers, metal surfaces, liquid-crystal and glass material.
  2. Mounted on movable modules.
 Illumination Spot Lights; 3AM OD14-ID8 Download 3.7V 40g 2.0W Green
MB-LPP-24 Metaphase Technologies Pattern Projector is designed to give the most accurate measurements in 3D profiling applications. By utilizing LED Patterns, structured light can illuminate a sample from overhead or at a needed angle. The LED Pattern Projector is built to tilt light on a sample surface to ensure that focus is clear throughout application use. LED Pattern projector illuminates a variety of patterns at different working distances. Paired with a lens and pattern reticle, the LED pattern projector is ideal for structured light applications. The device intensity can be controlled with a 0 ~ 10V intensity control signal. Optional manual dimmer available. Illumination Spot Lights; Metaphase Download 24V 0.226kg
FR-SL205-R-24-N Metaphase’s new LED spotlight provides low cost, washdown illumination. These new illuminators are available in a variety of beam angles and optimal working distances. These lights are housed in rugged waterproof housing that can stand up to high pressure washdown environments.The standard spotlight has a coverage area of 8ft at a distance of 8ft. Other angles include: ± 12°, ± 16°, and ± 25° No expensive external current driver is required. The lights include an adjustable locking mounting bracket. Illumination Spot Lights; Metaphase 1.7ʺ Download 24V Red
FR-SL205-R-24-M Metaphase’s new LED spotlight provides low cost, washdown illumination. These new illuminators are available in a variety of beam angles and optimal working distances. These lights are housed in rugged waterproof housing that can stand up to high pressure washdown environments.The standard spotlight has a coverage area of 8ft at a distance of 8ft. Other angles include: ± 12°, ± 16°, and ± 25° No expensive external current driver is required. The lights include an adjustable locking mounting bracket. Illumination Spot Lights; Metaphase 1.7ʺ Download 24V Red
FR-SL205-R-24-W Metaphase’s new LED spotlight provides low cost, washdown illumination. These new illuminators are available in a variety of beam angles and optimal working distances. These lights are housed in rugged waterproof housing that can stand up to high pressure washdown environments.The standard spotlight has a coverage area of 8ft at a distance of 8ft. Other angles include: ± 12°, ± 16°, and ± 25° No expensive external current driver is required. The lights include an adjustable locking mounting bracket. Illumination Spot Lights; Metaphase 1.7ʺ Download 24V Red
FR-SL205-B-24-N Metaphase’s new LED spotlight provides low cost, washdown illumination. These new illuminators are available in a variety of beam angles and optimal working distances. These lights are housed in rugged waterproof housing that can stand up to high pressure washdown environments.The standard spotlight has a coverage area of 8ft at a distance of 8ft. Other angles include: ± 12°, ± 16°, and ± 25° No expensive external current driver is required. The lights include an adjustable locking mounting bracket. Illumination Spot Lights; Metaphase 1.7ʺ Download 24V Blue
FR-SL205-B-24-M Metaphase’s new LED spotlight provides low cost, washdown illumination. These new illuminators are available in a variety of beam angles and optimal working distances. These lights are housed in rugged waterproof housing that can stand up to high pressure washdown environments.The standard spotlight has a coverage area of 8ft at a distance of 8ft. Other angles include: ± 12°, ± 16°, and ± 25° No expensive external current driver is required. The lights include an adjustable locking mounting bracket. Illumination Spot Lights; Metaphase 1.7ʺ Download 24V Blue
FR-SL205-B-24-W Metaphase’s new LED spotlight provides low cost, washdown illumination. These new illuminators are available in a variety of beam angles and optimal working distances. These lights are housed in rugged waterproof housing that can stand up to high pressure washdown environments.The standard spotlight has a coverage area of 8ft at a distance of 8ft. Other angles include: ± 12°, ± 16°, and ± 25° No expensive external current driver is required. The lights include an adjustable locking mounting bracket. Illumination Spot Lights; Metaphase 1.7ʺ Download 24V Blue
FR-SL205-G-24-N Metaphase’s new LED spotlight provides low cost, washdown illumination. These new illuminators are available in a variety of beam angles and optimal working distances. These lights are housed in rugged waterproof housing that can stand up to high pressure washdown environments.The standard spotlight has a coverage area of 8ft at a distance of 8ft. Other angles include: ± 12°, ± 16°, and ± 25° No expensive external current driver is required. The lights include an adjustable locking mounting bracket. Illumination Spot Lights; Metaphase 1.7ʺ Download 24V Green
FR-SL205-G-24-M Metaphase’s new LED spotlight provides low cost, washdown illumination. These new illuminators are available in a variety of beam angles and optimal working distances. These lights are housed in rugged waterproof housing that can stand up to high pressure washdown environments.The standard spotlight has a coverage area of 8ft at a distance of 8ft. Other angles include: ± 12°, ± 16°, and ± 25° No expensive external current driver is required. The lights include an adjustable locking mounting bracket. Illumination Spot Lights; Metaphase 1.7ʺ Download 24V Green
FR-SL205-G-24-W Metaphase’s new LED spotlight provides low cost, washdown illumination. These new illuminators are available in a variety of beam angles and optimal working distances. These lights are housed in rugged waterproof housing that can stand up to high pressure washdown environments.The standard spotlight has a coverage area of 8ft at a distance of 8ft. Other angles include: ± 12°, ± 16°, and ± 25° No expensive external current driver is required. The lights include an adjustable locking mounting bracket. Illumination Spot Lights; Metaphase 1.7ʺ Download 24V Green
HLV2-28UV

Ultraviolet (UV) Series Features:

  1. A peak emission wavelength of 365 nm.
  2. Provide image recognition at high contrast.
  3. Capture the surface of the subject more clearly than visible light.



Major applications:

  1. Photography use the difference in the scattering rate.
  2. Use with a CCD camera supporting the ultraviolet ray range.
  3. Detection of dirt on glass substrates and dust on CCD devices.
  4. Scan the image of the OR Code.
 Illumination Spot Lights; 3AM 55.5x28mm Download 39g 1.0W UV (405nm)
HLV2-28UV365

Ultraviolet (UV) Series Features:

  1. A peak emission wavelength of 365 nm.
  2. Provide image recognition at high contrast.
  3. Capture the surface of the subject more clearly than visible light.



Major applications:

  1. Photography use the difference in the scattering rate.
  2. Use with a CCD camera supporting the ultraviolet ray range.
  3. Detection of dirt on glass substrates and dust on CCD devices.
  4. Scan the image of the OR Code.
 Illumination Spot Lights; 3AM OD14-ID8 Download 39g 1.0W UV (365nm)
FR-SL205-IR-24-N Metaphase’s new LED spotlight provides low cost, washdown illumination. These new illuminators are available in a variety of beam angles and optimal working distances. These lights are housed in rugged waterproof housing that can stand up to high pressure washdown environments.The standard spotlight has a coverage area of 8ft at a distance of 8ft. Other angles include: ± 12°, ± 16°, and ± 25° No expensive external current driver is required. The lights include an adjustable locking mounting bracket. Illumination Spot Lights; Metaphase 1.7ʺ Download 24V Infra-Red (850nm)
FR-SL205-IR-24-M Metaphase’s new LED spotlight provides low cost, washdown illumination. These new illuminators are available in a variety of beam angles and optimal working distances. These lights are housed in rugged waterproof housing that can stand up to high pressure washdown environments.The standard spotlight has a coverage area of 8ft at a distance of 8ft. Other angles include: ± 12°, ± 16°, and ± 25° No expensive external current driver is required. The lights include an adjustable locking mounting bracket. Illumination Spot Lights; Metaphase 1.7ʺ Download 24V Infra-Red (850nm)
FR-SL205-IR-24-W Metaphase’s new LED spotlight provides low cost, washdown illumination. These new illuminators are available in a variety of beam angles and optimal working distances. These lights are housed in rugged waterproof housing that can stand up to high pressure washdown environments.The standard spotlight has a coverage area of 8ft at a distance of 8ft. Other angles include: ± 12°, ± 16°, and ± 25° No expensive external current driver is required. The lights include an adjustable locking mounting bracket. Illumination Spot Lights; Metaphase 1.7ʺ Download 24V Infra-Red (850nm)
GL-HLV2-24UV365-1W

Ultraviolet (UV) Series Features:

  1. A peak emission wavelength of 365 nm.
  2. Provide image recognition at high contrast.
  3. Capture the surface of the subject more clearly than visible light.



Major applications:

  1. Photography use the difference in the scattering rate.
  2. Use with a CCD camera supporting the ultraviolet ray range.
  3. Detection of dirt on glass substrates and dust on CCD devices.
  4. Scan the image of the OR Code.
 Illumination Spot Lights; 3AM OD14-ID8 Download 55g 1.0W
GL-HLV2-24W-5W

Coaxial Series Features

  1. Coaxial lights are mainly designed for objects with highly reflective surfaces
  2. Allowing to produce simulated even coaxiial lighting for TELECENTRIC MACRO lens and other type of lenses.



Major applications

  1. Inspection for highly reflective surfaces, such as wafers, metal surfaces, film, liquid crystals and glass.
  2. Imprint check
  3. Inspection of pattern of printed boards.
 Illumination Spot Lights; 3AM OD14-ID8 Download 3.5V 153g 5W White
VL-CS0814R Illumination Spot Lights vs Download 12V 12g 0.6W Red Download
VL-CS0814W Illumination Spot Lights vs Download 12V 12g 0.5W White Download
VL-CS0814B Illumination Spot Lights vs Download 12V 12g 0.8W Blue Download
VL-CS2414R Illumination Spot Lights vs Download 24V 14g 0.8W Red Download
VL-CS2414W Illumination Spot Lights vs Download 24V 14g 1.0W White Download
VL-CS2414B Illumination Spot Lights vs Download 24V 14g 0.9W Blue Download
VL-CS2414G Illumination Spot Lights vs 24V 14g 0.8W Green Download
VL-CSN2414R Illumination Spot Lights vs Download 24V 16g 1.0W Red Download
VL-CSN2414W Illumination Spot Lights vs Download 24V 16g 1.0W White Download
VL-CSN2414B Illumination Spot Lights vs Download 24V 16g 1.0W Blue Download
VL-CSN2414G Illumination Spot Lights vs Download 24V 16g 1.0W Green Download
 GL-HLV2-32WRGB
♦Features

1. It enables dimming each color independently.
2. Blend the colors as user want.

♦Major applications

1. BGA solder ball position, shape and area in inspection.
2. Inspection of wafers or glass substrates for scratches and stain.
3. Reading laser engraving.
4. Edge detection and defect inspection.

 Illumination Spot Lights; 3AM OD14-ID8 Download 4.0W WRGB
GL-HLV2-24G-3W

Coaxial Series Features

  1. Coaxial lights are mainly designed for objects with highly reflective surfaces
  2. Allowing to produce simulated even coaxiial lighting for TELECENTRIC MACRO lens and other type of lenses.



Major applications

  1. Inspection for highly reflective surfaces, such as wafers, metal surfaces, film, liquid crystals and glass.
  2. Imprint check
  3. Inspection of pattern of printed boards.
 Illumination Spot Lights; 3AM OD14-ID8 Download 24V 3W Green
GL-HLV2-6040RGB

Versatile and Precise RGB LED Spotlights for Enhanced Inspections RGB LED spotlight is a versatile lighting solution that can be applied in conjunction with a Telecentric Lens. This special design emits high-intensity spotlights and allows for independent dimming of each color. By leveraging the RGB capability, illumination colors such as yellow, light blue, and pink can be easily mixed. This not only saves valuable working hours spent on changing lights but also reduces costs associated with machine light replacements. 3AM RGB LED spotlight finds applications in surface defect detection, dimensional measurement, dents on metal surfaces, panel screen coding, and glass target alignment.

Features:

  • Compatible with telecentric lens
  • It enables dimming each color independently. The light colors are red, green & blue
  • Adjust the lighting color for different inspection
  • The RGB light can provide the good illumination
  • Reduce lamp replacement working hours and costs
 Illumination Spot Lights 3AM Download 5W
Go to Search
Contact Us
